Gvision Header Tank Heat Exchanger

The Gvision Header Tank Heat Exchanger System is aimed to maintain & regulates engine coolant temperature.

What it is, for All About.

The Gvision Header Tank Heat Exchanger System is aimed to maintain & regulates engine coolant temperature. A header tank is a tank or reservoir that is mounted at the top of a device to maintain static pressure on a fluid

Gvision-Header-Tank-Heat-Exchanger
Gvision Header Tank Heat Exchanger

Specification of Gvision Header Tank Heat Exchanger

The Gvision Header Tank Heat Exchanger System is aimed to maintain & regulates engine coolant temperature within very narrowband (+/- 0.1 under specified condition) and eliminate temperature error in engine testing.

Technical Specification :

  • Media: Water / Coolant
  • Water Flow Rate (lpm): 120 lpm
  • Set Temp. Range : 75-120 deg C
  • Temp. Stability : +/- 1 deg C
  • Temp. Indicator Stability : +/- 0.1 deg C
  • Require Cooling Raw Water Temp.vs kg/cm2 : 15 – 30 C / 2
  • Control Circuit : External
  • Engine Power (HP) : 75 – 250
  • Power Supply : 230 V AC 1A
  • Interfacing (Both way) : RS 232
  • Air / Steam Bubbles removing Facility : Available
  • Pressure relief valve / cap : Available
  • Inbuilt heating arrangement.
Overview

In inclusion, when utilized in concert, the Gvision Header Tank Heat Exchanger System become a highly accurate coolant temperature controller. Furthermore, fast calibration, easy integration, as well as long maintenance intervals are key features of our system that delivers quality results with minimum downtime.
